Auto Focus USB camera module application The action camera with Sony imx214
- High-Definition Imaging with Sony IMX214 Sensor: Equipped with Sony’s premium IMX214 image sensor, it captures every intricate detail with stunning clarity and accurate color reproduction, delivering professional-grade visuals for both landscapes and action shots.
- Auto Focus for Intelligent Capture: Boasting a precise auto-focus system, it swiftly responds and intelligently identifies the subject, ensuring every shot, whether dynamic or static, is pinpoint focused for unparalleled accuracy.
- USB Plug-and-Play for Convenience: Directly connect via USB to your PC, laptop, or mobile device, eliminating complex setups. Experience seamless integration and instant access to your creative photography journey, enhancing productivity.
- Compact & Lightweight for Versatility: Designed to be compact and lightweight, it’s easy to carry around, making it ideal for outdoor adventures, live streaming, video conferencing, and more, catering to your diverse needs.
- Stable & Durable for Reliability: Crafted from high-quality materials and rigorously tested, this camera ensures stability and longevity, maintaining exceptional performance over time. It’s a dependable companion on your photography journey.
https://www.sony-semicon.com/en/products/is/camera/index.html
Detail Information
| Type: | USB Camera Module | Sensor: | 1/3’’ sony imx214 |
|---|---|---|---|
| Resolution: | 3840*2160 | Dimensions: | Customizable |
| Lens FOV: | 100°(optional) | Focus Type: | Fixed Focus |
| Interface: | USB2.0 | Feature: | Lens |
Key Feature:
8MP resolution with SONY IMX214 CMOS sensor
Fixed Focus
High sensitivity, high dynamic range
UVC compliant, Plug & Play
Support Linux, Android, Mac and Windows
Customization is supported
It supports the below resolution & frame rate:
MJPG:
3840*2160 30fps 2592*1944 30fps
2048*1536 30fps 1920*1080 30fps
1280*720 30fps 800*600 30fps
640*480 30fps 320*240 30fps
Specification
| Model No | hstd-40MP-imx214-FF-mipi |
| Sensor | 1/3’’ SONY IMX214 CMOS |
| Pixel | 8 Mega Pixel |
| Most effective pixels | 3840*2160 20FPS |
| Pixel Size | 1.4µm x 1.4µm |
| Focus type | Fixed Focus |
| Compression format | MJPG(optional) |
| Resolution & Frame rate | See above |
| Shutter Type | Electronic rolling shutter |
| Chroma | Color, RGB |
| Interface type | USB2.0 |
| Protocol & Connection | Plug-&-Play (UVC compliant) |
|
Adjustable Parameters |
Brightness/Contrast/Color saturation/Hue/Definition/
Gamma/White balance/Exposure |
|
Lens |
H FOV: 100° |
| F/NO=2.4 | |
| Focal length: 2.8mm | |
| Thread size: M12*P0.5 | |
| Audio frequency | Optional |
| Power supply | USB BUS POWER |
| Operating Voltage | DC 5V |
| Operating Current | 300mA |
| Main chip | DSP/SENSOR/FLASH |
| Auto Exposure Control (AEC) | Supported |
| Auto White Balance (AEB) | Supported |
| Auto Gain Control (AGC) | Supported |
| Dimension | 38MMx38MM (Compatible with 32MMx32MM) |
| Storage temperature | -20°C to 70°C |
| Operating temperature | 0°C to 60°C |
| USB cable length | Default |
|
Support OS |
WinXP/Vista/Win7/Win8/Win10
Linux with UVC（above linux-2.6.26） MAC-OS X 10.4.8 or later Android 4.0 or above with UVC |
